• All PFA construction
• Compatible with both 820-01 and 820-02 PFA cyclonic spray chambers
• Connects to Spectro ICP-OES, radial type only, with ESI inert torch
• Requires ESI inert torch for Spectro ICP-OES. Connects directly to ESI inert torch base
• Choose 821-105 if Spectro demountable torch is used

Exit Port/Connector, Spectro Arcos Radial without Baffle

821-112

• All PFA construction
• Compatible with both 820-01 and 820-02 PFA cyclonic spray chambers
• Connects to Spectro ICP-OES, radial type only, with ESI inert torch
• Requires ESI inert torch for Spectro ICP-OES. Connects directly to ESI inert torch base
• Choose 821-105 if Spectro demountable torch is used

• All PFA construction
• Compatible with both 820-01 and 820-02 PFA cyclonic spray chambers (820-02 is recommended)
• Connects to: Thermo iCAP ICP-OES Duo type only (for radial version use 821-111)
• Connects direct to standard Thermo torch base

Exit port/connector for Thermo iCAP Duo ICP-OES, without baffle

821-114

• All PFA construction
• Compatible with both 820-01 and 820-02 PFA cyclonic spray chambers (820-02 is recommended)
• Connects to: Thermo iCAP ICP-OES Duo type only (for radial version use 821-111)
• Connects direct to standard Thermo torch base

• All PFA construction
• Compatible with both 820-01 and 820-02 PFA cyclonic spray chambers (820-02 is recommended)
• Connects to Spectro Arcos II ICP-OES (but only when the Glass Expansion (GE) D-Type torch is used)
• Connects direct to GE D-Type torch base



Exit Port/Connector for Spectro Arcos II with GE D-Type Torch with Baffle

821-115

• All PFA construction
• Compatible with both 820-01 and 820-02 PFA cyclonic spray chambers (820-02 is recommended)
• Connects to Spectro Arcos II ICP-OES (but only when the Glass Expansion (GE) D-Type torch is used)
• Connects direct to GE D-Type torch base

• 4 mm OD PTFE tubing
• Length:3.65 m (12 ft)
• Used for Argon gas supply line to ICP nebulizers

4 mm PTFE Tubing

830-030

• 4 mm OD PTFE tubing
• Length:3.65 m (12 ft)
• Used for Argon gas supply line to ICP nebulizers

• High purity PFA gas line for use with nebulizer or make up gas
• Length
  • 3 m (9.84 ft)

4 mm OD PFA Gas Tubing

830-031

• High purity PFA gas line for use with nebulizer or make up gas
• Length
  • 3 m (9.84 ft)

• Interchangeable uptake line (70 cm ) for X-Flow nebulizer
• Push fit, zero dead volume fitting
• X-flow is designed to be pumped but free aspirates at 400 uL/min with this uptake line

400 µl X-Flow Uptake Line Assembly

830-041

• Interchangeable uptake line (70 cm ) for X-Flow nebulizer
• Push fit, zero dead volume fitting
• X-flow is designed to be pumped but free aspirates at 400 uL/min with this uptake line

• Interchangeable uptake line (70 cm) for X-Flow nebulizer
• Push fit, zero dead volume fitting
• X-flow is designed to be pumped but fre aspirates at 1mL/min with this uptake line

1 ml X-Flow Uptake Line Assembly

830-042

• Interchangeable uptake line (70 cm) for X-Flow nebulizer
• Push fit, zero dead volume fitting
• X-flow is designed to be pumped but fre aspirates at 1mL/min with this uptake line

  $91.14

• Removable uptake line, 0.3 mm ID
• 80 cm length
• Savillex PFA zero dead volume connector
• For d-type (i.e. C-Flow 400d or 700d)) nebulizer bodies only

Replacement Uptake Line for C-Flow "d-type" Nebulizers

830-050

• Removable uptake line, 0.3 mm ID
• 80 cm length
• Savillex PFA zero dead volume connector
• For d-type (i.e. C-Flow 400d or 700d)) nebulizer bodies only

The C-Flow features a reliable and secure threaded connector that accepts 4 mm OD nylon or PTFE gas line. However, for easy connection to the various gas lines found in different ICP-OES and ICP-MS instruments, a gas connection kit is included with each C-Flow (except C-Flow for Aridus II). The connection kit includes:

• One meter of 4 mm OD PTFE gas line (connects to the threaded connector on the C-Flow body)
• A Festo 4 mm/6 mm push fit connector (connects the supplied 4mm OD PTFE gas line to the 6 mm OD nylon gas line used in some instruments)
• A barbed connector. The plain end of this connector connects to the threaded connector on the C-Flow body. The barbed end accepts Tygon gas line, which is commonly used on ICP-OES instruments.
• Note: the PE NexION 2000 serice icp-MS uses 1/8" gas line. To connect a C-Flow to a NexION 2000, please order part #830-052.

C-Flow Gas Line Connection Kit

830-051

The C-Flow features a reliable and secure threaded connector that accepts 4 mm OD nylon or PTFE gas line. However, for easy connection to the various gas lines found in different ICP-OES and ICP-MS instruments, a gas connection kit is included with each C-Flow (except C-Flow for Aridus II). The connection kit includes:

• One meter of 4 mm OD PTFE gas line (connects to the threaded connector on the C-Flow body)
• A Festo 4 mm/6 mm push fit connector (connects the supplied 4mm OD PTFE gas line to the 6 mm OD nylon gas line used in some instruments)
• A barbed connector. The plain end of this connector connects to the threaded connector on the C-Flow body. The barbed end accepts Tygon gas line, which is commonly used on ICP-OES instruments.
• Note: the PE NexION 2000 serice icp-MS uses 1/8" gas line. To connect a C-Flow to a NexION 2000, please order part #830-052.

The C-Flow features a reliable and secure threaded connector. Most ICP-OES and ICP-MS instruments use 4mm or 6mm OD gas line that the standard C-Flow Gas Line Connection Kit is designed for. However the PE NexION 2000 series ICP-MS uses a 1/8in fitting on the nebulizer gas supply. This kit connects the 1/8in gas supply directly to the C-Flow. The kit includes:

• One foot of 1/8in OD PFA gas line
• A 1/8in PVDF nut to connect to the NexION gas suppply
• A PFA nut to connect to the C-Flow body

C-Flow Gas Line Connection Kit - PE NexION 2000

830-052

The C-Flow features a reliable and secure threaded connector. Most ICP-OES and ICP-MS instruments use 4mm or 6mm OD gas line that the standard C-Flow Gas Line Connection Kit is designed for. However the PE NexION 2000 series ICP-MS uses a 1/8in fitting on the nebulizer gas supply. This kit connects the 1/8in gas supply directly to the C-Flow. The kit includes:

• One foot of 1/8in OD PFA gas line
• A 1/8in PVDF nut to connect to the NexION gas suppply
• A PFA nut to connect to the C-Flow body

• For s-type nebulizer bodies
• Unique zero dead volume connection
• 100 cm PFA uptake line - no probe
• Nebulizer uptake rate not guaranteed to be within original specification when uptake line is changed

Uptake Line for C50s Nebulizer

830-061

• For s-type nebulizer bodies
• Unique zero dead volume connection
• 100 cm PFA uptake line - no probe
• Nebulizer uptake rate not guaranteed to be within original specification when uptake line is changed

• For s-type nebulizer bodies
• Unique zero dead volume connection
• 70 cm uptake line; comprised of ~60 cm of flexible uptake line and ~10 cm polyamide probe
• Encapsulated polyimide probe 2.8 mm OD, 102 mm long - compatible with Agilent I-AS autosampler only
• Nebulizer uptake rate not guaranteed to be within original specification when uptake line is changed

Uptake Line for C50s Nebulizer with Autosampler Probe (70 cm)

830-062

• For s-type nebulizer bodies
• Unique zero dead volume connection
• 70 cm uptake line; comprised of ~60 cm of flexible uptake line and ~10 cm polyamide probe
• Encapsulated polyimide probe 2.8 mm OD, 102 mm long - compatible with Agilent I-AS autosampler only
• Nebulizer uptake rate not guaranteed to be within original specification when uptake line is changed
